QC350 CNC Medium Speed Molybdenum Wire Cut EDM Electric Discharge Machining

  • QC350 CNC Medium Speed Molybdenum Wire Cut EDM Electric Discharge Machining
  • QC350 CNC Medium Speed Molybdenum Wire Cut EDM Electric Discharge Machining
  • QC350 CNC Medium Speed Molybdenum Wire Cut EDM Electric Discharge Machining
  • QC350 CNC Medium Speed Molybdenum Wire Cut EDM Electric Discharge Machining
  • QC350 CNC Medium Speed Molybdenum Wire Cut EDM Electric Discharge Machining
Model No.︰QC350
Brand Name︰SHENYANG
Country of Origin︰China
Unit Price︰US $ 1 / pc
Minimum Order︰1 pc
Share on:

 Total 19 Related Items
Prev1516171819

Product Description

~Automations
1. Wire tension automatic control, No need to tighten the wire manually. Constant tension and stable accuracy.
2. the Z axis can move by automatic. No need to remove the wire.
3. Intelligent setting the cut parameter, operation is handy.
4. Wire diameter automation control. Reduction the accuracy error which caused by the change of the wire diameter.

QC series has more stable structural design for Z axis. The machine table is fully supported structure (consistent with the machining center) , And use Japanese THK linear guide , Ensure high rigidity of the machine tool under high load. Bearings is NSK which imported from Japan. Equiped Panasonic AC servo motor.

the important precision index. (with out wire guider!!)
1. Roughness:  Ra≤1.0um/30000mm2.
2. Accuracy of the machining: ≤±0.005mm.
3. Conformance deviation: ≤0.005mm/30pcs.
4. Longitudinal dimension deviation: ≤0.005/100 mm.















Payment Terms︰TT/LC
